Duplex Flat Fig 8 Zipcord Serat Optik Zipcord

Duplex Flat Cable 8 Zipcord kabel Optik Zipcord nggunakake φ900μm utawa φ600um serat optik sing ketat, ditutupi kanthi bahan transmisik optik, lan lszh, rokok, asap-asap, FLAME-Retardant) sarung.

Kirim Pitakonan

Deskripsi Produk

Karakteristik

Gampang serat sing gampang diluncurake

Serat Buffer sing kenceng duwe kinerja retace sing apik banget

Unsur pengenuhan aramid menehi kekuatan tegor sing apik banget

Sheath berbentuk 8 gampang kanggo pipis lan digunakake kanggo cabang

Bahan njaba yaiku tahan karat, anti banyu, tahan UV, Flame-Retardant lan ramah lingkungan.

Aplikasi

Duplex Optical Serat Patchcord utawa Pigtail

Distribusi njero ruangan

Campursional antarane instrumen, peralatan komunikasi

Standar

Ketemu standar YD / T 1258.2, Icea-596, GR-409, IEC 60794-2-10 / 11, lan sapiturute ing saliyane produk PVC sing biasa, uga ana produk sing wis lulus Ulofnr lan OFNP Sertifikasi. Produk lszh nggunakake bahan sing beda kanggo ketemu iEc60332-1 utawa iEc60332-C utawa offigations n.

Gambar struktur

1.Thigh serat Buffer

Jaket benang 2.aramid

3.jacket

Duplex Flat Fig 8 Zipcord Fiber Optic Cable

Paramèter teknis

Model kabel	Kabel Diameter (Ref) (Mm)	Bobot kabel (Ref) e o		Diameteripun tbf (Μm)	Kekuwatan tensile Jangka panjang / jangka pendek (N)	Rintangan crush Jangka panjang / jangka pendek (N / 100mm)	Bending radius Dinamika / statis (mm)
Model kabel	Kabel Diameter (Ref) (Mm)	Jaket Pvc	Jaket lszh	Diameteripun tbf (Μm)	Kekuwatan tensile Jangka panjang / jangka pendek (N)		Bending radius Dinamika / statis (mm)
1.6	(3,4 ± 0,3) × (1,6 ± 0,3)	4.8	5.3	600 ± 50	40/80	100/500	60/30
1.9	(4.0 ± 0,3) × (1.9 ± 0,3)	8.0	8.7	900 ± 50	100/200	100/500	60/30
2.8	(5.8 ± 0,3) × (2,8 ± 0,3)	11.6	14.8	900 ± 50	100/200	100/500	60/30

Karakteristik Optik

Jinis serat	Attenuation				OFL	Bandwidth Mode Efektif	10 Gbit Ethernet Link Link	Radius Bend minimal
Kondisi	1310 / 1550nm		850 / 1300NM		850 / 1300NM	850nm	850nm	/
Kondisi	Nilai khas	Nilai maksimal	Nilai khas	Nilai maksimal	850 / 1300NM	850nm	850nm	/
Unit	db / km	db / km	db / km	db / km	MHz.KM	MHz.KM	m	mm
G652d	0.36 / 0.22	0,5 / 0.4	---	---	---	---	---	16
G657a1	0.36 / 0.22	0,5 / 0.4	---	---	---	---	---	10
G657a2	0.36 / 0.22	0,5 / 0.4	---	---	---	---	---	7.5
50/125	---	---	3.0 / 1.0	3.5 / 1,5	≥500 / 500	---	---	30
62.5 / 125	---	---	3.0 / 1.0	3.5 / 1,5	≥200 / 500	---	---	30
Om3	---	---	3.0 / 1.0	3.5 / 1,5	≥1500 / 500	≥2000	≤300	30
Om4	---	---	3.0 / 1.0	3.5 / 1,5	≥3500 / 500	≥4700	≤550	30
