Kabel Optik Serat Simplex

Kabel Optik Serat Simplex nggunakake siji φ900μm utawa φ600μm sing ora sopan minangka medium polivinl klorida (lszh, rokok, halog-free, flamen-record, flamen-free, flame-retartant).

Kirim Pitakonan

Deskripsi Produk

Karakteristik

Serat buffer sing gampang gampang diikat

Serat Buffer sing kenceng duwe kinerja retace sing apik banget

Benang Aramid minangka Anggota Kekuwatan Gawe kabel optik serat Simplex duwe kekuwatan tegor sing apik banget

Jaket jaket njaba duwe akeh kaluwihan kayata anti-corrosion, anti-banyu, radiasi anti-ultraviolet, flame-mundur lan ora mbebayani kanggo lingkungan lsp.

Aplikasi

Nggawe tali patch utawa pigtails

Distribusi njero ruangan

Sambungake antarane instrumen, peralatan komunikasi

Standar

Ketemu standar YD / T 1258.2, Icea-596, GR-409, IEC 60794-2-10 / 11, lan sapiturute ing saliyane produk PVC sing biasa, uga ana produk sing wis lulus Ulofnr lan OFNP Sertifikasi. Produk lszh nggunakake bahan sing beda kanggo ketemu IEC60332-1 utawa iEc60332-C utawa iEnr.

Gambar struktur

1.Thigh serat Buffer

2.aramid benang

3.jacket

Simplex Fiber Optic Cable

Paramèter teknis

Model kabel	Kabel Diameter (Ref) (mm)	Bobot kabel (Ref) (kg / km)		Diameteripun tbf (μm)	Tensile Strenght Jangka panjang / jangka pendek (N)	Rintangan crush Jangka panjang / jangka pendek (N / 100mm)	Bending radius Dinamika / statis (mm)
Model kabel	Kabel Diameter (Ref) (mm)	Jaket Pvc	Jaket lszh	Diameteripun tbf (μm)	Tensile Strenght Jangka panjang / jangka pendek (N)		Bending radius Dinamika / statis (mm)
1.6	1,6 ± 0.2	2.4	2.6	600 ± 50	40/80	100/500	60/30
1.9	1.9 ± 0,2	3.5	4.5	900 ± 50	60/100	100/500	60/30
2.8	2.8 ± 0.2	6.0	7.5	900 ± 50	60/100	100/500	60/30

Karakteristik Optik

Jinis serat	Attenuation				OFL	Bandwidth Mode Efektif	10 Gbit Ethernet Link Link	Radius Bend minimal
Kondisi	1310 / 1550nm		850 / 1300NM		850 / 1300NM	850nm	850nm	/
Kondisi	Nilai khas	Nilai maksimal	Nilai khas	Nilai maksimal	850 / 1300NM	850nm	850nm	/
Unit	db / km	db / km	db / km	db / km	MHz.KM	MHz.KM	m	mm
G652d	0.36 / 0.22	0,5 / 0.4	---	---	---	---	---	16
G657a1	0.36 / 0.22	0,5 / 0.4	---	---	---	---	---	10
G657a2	0.36 / 0.22	0,5 / 0.4	---	---	---	---	---	7.5
50/125	---	---	3.0 / 1.0	3.5 / 1,5	≥500 / 500	---	---	30
62.5 / 125	---	---	3.0 / 1.0	3.5 / 1,5	≥200 / 500	---	---	30
Om3	---	---	3.0 / 1.0	3.5 / 1,5	≥1500 / 500	≥2000	≤300	30
Om4	---	---	3.0 / 1.0	3.5 / 1,5	≥3500 / 500	≥4700	≤550	30
