Kabel Vertikal Indoor FTTH
Bangunan trunk wiring kabel optik
Desain struktural sing apik, gampang cabang lan ekstrak
Ukuran cilik, bobote entheng, gampang diinstal
Sheak Slowen-Gratis Halogen-Gratis njamin retardancian murub sing apik
Kontrol proses presaris njamin kinerja mekanik lan suhu
Apike kanggo nglereni, ekstraksi, bukaan Skylight
| Jinis kabel | Diameter kabel | Bobot kabel | Kekuwatan tensile dawa / jangka pendek | Rintangan crush dawa / Short | Radius Dinamika / Statis | Suhu panyimpenan |
| (mm) | (kg / km) | (N) | (N) | (mm) | (℃) | |
| Gjpfwqh-24 (4cx6s) | 6,5 ± 0,2 | 40 | 200/500 | 200/1000 | 20d / 10d | -20 ° C ~ +60 |
| Gjpfwqh-48 (4cx12s) | 8.5 ± 0.2 | 60 | 200/500 | 200/1000 | 20d / 10d | -20 ° C ~ +60 |
| Gjpfwqh-96 (8cx12s) | 10.5 ± 0.2 | 90 | 200/500 | 200/1000 | 20d / 10d | -20 ° C ~ +60 |
| Gjpfwqh-144 | 10.5 ± 0.2 | 90 | 300/500 | 200/1000 | 20d / 10d | -20 ° C ~ +60 |
| Gjpfwqh-144 | 13.5 ± 0.2 | 145 | 300/500 | 200/1000 | 20d / 10d | -20 ° C ~ +60 |
Cathetan: Suhu transportasi / panyimpenan: -20 ° C ~ + 60 ° C
Dawane standar: 2000m; Dawane liyane uga kasedhiya.
Tipe Serat: G652d, G657A1, G657a2, 50/125, 62,5 / 125, OM4, Om5, OM5,
